Demolition and Recycling
Operationeel gewicht 30 - 50 t
SPECIFICATIONS

Key specifications for SK210D-11E

Description
Telematics Available Yes
Rear View Camera Yes
Boom Size 5.65 m
Dipper Length 2940 mm
Dipper Type Heavy Duty
Cab Riser No
Engine
Engine Manufacturer Yanmar
Engine Model 4TN107FTT
Cylinders 4
Aspiration Turbo intercooler
Exhaust System DOC-DPF-SCR
Cooling Water
Displacement 4.567 L
Rated Speed 2000 rpm
Gross Rating Standard ISO 14396
Gross Output 127 kW
Torque 805 Nm
Driveline
Variable Undercarriage Available No
Width Over Tracks 2800 mm
Shoe Type Triple grouser
Shoe Width 600 mm
Dimensions
Demolition Boom 9650 mm
Over Demolition Boom 3490 - 3550 mm
Overall Width 2800 - 2850 mm
Max Machine Width 2800 - 2850 mm
Tailswing Radius 2900 mm
Track Length On Ground 3370 mm
Undercarriage Length 4170 mm
Min Cab Height 3110 mm
Max Cab Height 3110 mm
Counterweight Clearance 1140 mm
Superstructure Width 2710 mm
Max Reach 10970 - 11070 mm
Ground Level Reach 5230 - 5260 mm
Max Height 10920 - 11010 mm
Min Dump Height 5910 - 6020 mm
Capacities
Fuel Tank 321 L
DEF Tank 83 L
Hydraulic Tank 140 L
Hydraulic System 270 - 300 L
Engine Oil 20 L
Swing Oil 2.7 L
Cooling System 23 L
Performance
Slew Speed 12.7 rpm
Slew Torque 71.5 kNm
Travel Speed Low 3.6 kph
Travel Speed High 6 kph
Hydraulic System
Pump Type Variable axial piston
Main Pumps 2
Max Flow Per Pump 220 L/min
Main Pumps Max Flow 440 L/min
Hydraulic System Max Pressure 343 bar
Attachment Pressure 294 bar
Weights
Operating Weight 27500 - 30500 kg
Ground Bearing Pressure 62 - 68 kPa
Demolition Boom Specification Weight 27500 - 30500 kg
Demolition Boom Ground Pressure 62 - 68 kPa
Attachment Type Nibbler
Attachment Weight 1900 - 2100 kg
