SK260LC-10
SK260LC-10
SK260LC-10
SK260LC-10
SK260LC-10
SK260LC-10

SK260LC-10

Conventional Excavators
Operationeel gewicht 18 - 30 t
SPECIFICATIONS

Key specifications for SK260LC-10

Description
Number Of Boom Options 1
Rear View Camera Yes
Number Of Mono Booms 1
Boom Size 6.02 m
Number Of Dipper Options 3
Min Dipper Length 2500 mm
Max Dipper Length 3660 mm
Dipper Length 2980 mm
Operating Weight 25500 kg
Telematics
Available Yes
Driveline
Manufacturer Hino
Model J05ETB
Aspiration Turbo, charge air cooled
Charged Air Cooling Intercooler
EGR Exhaust Gas Recirculation
Cooling Water
Cylinders 4
Displacement 5.123 L
Rated Speed 2100 rpm
Net Rating Standard ISO 9249
Net Output 132 kW
Gross Rating Standard ISO 14396
Gross Output 137 kW
Torque 651 Nm
Torque Rated Speed 1600 rpm
Carrier Rollers Per Side 2
Track Rollers Per Side 9
Shoe Width 600 mm
Shoe Type Triple grouser
Track Shoes Per Side 51
Dimensions
Mono Boom 10210 mm
Over Boom 3180 mm
Without Boom 3040 mm
Max Height 3350 mm
Superstructure 2980 mm
Undercarriage 3190 mm
Overall Width 3390 mm
Track Length On Ground 3850 mm
Undercarriage Length 4640 mm
Tailswing Radius 3100 mm
Tail Length 3070 mm
Zero Tailswing No
Cab 3040 mm
Counterweight Clearance 1090 mm
Ground Clearance 460 mm
Capacity Rating Standard ISO
Reference Capacity 1 m³
Min Capacity 0.8 m³
Max Capacity 1.4 m³
Reference Weight 810 kg
Min Weight 700 kg
Max Weight 890 kg
Width Over Tracks 3190 mm
Track Gauge 2590 mm
Variable Undercarriage Available No
Digging Reach 10300 mm
Ground Level Reach 10140 mm
Dig Height 9790 mm
Dump Height 6880 mm
Vertical Wall 6150 mm
Dig Depth - 2.44m (8ft) Flat Bottom 6820 mm
Dig Depth 7000 mm
Front Slew Radius 3910 mm
Rating Standard ISO 10567
Reach At Ground Level 8.58 m
Capacities
Fuel Tank 403 L
Engine Oil 20.5 L
Cooling System 21 L
Hydraulic Tank 165 L
Hydraulic System 273 L
Performance
Ground Bearing Pressure 50 kPa
Slew Speed 10.8 rpm
Travel Speed - Low 3.8 kph
Travel Speed - High 6.1 kph
Tractive Force 244 kN
Boost Pressure Used For Breakout Yes
Dipper Tearout 130 kN
Bucket Breakout 187 kN
Gradeability 35 °
Gradeability 70 %
Lift Quoted With Bucket No
Lift Quoted With Quick-Hitch No
End Lift - 4.5m 11940 kg
Side Lift - 4.5m 8910 kg
End Lift - 6.0m 8630 kg
Side Lift - 6.0m 5940 kg
End Lift - 7.5m 6700 kg
Side Lift - 7.5m 4380 kg
End Lift - Max 5080 kg
Side Lift - Max 3640 kg
Main Pumps 2
Main Pump - Total 490 L/min
Boom 343 bar
Dipper 343 bar
Attachment 343 bar
Boost 378 bar
