Mini Excavators
Operationeel gewicht 0 - 6 t
SPECIFICATIONS

Key specifications for SK26SR-7

Description
Number Of Boom Options 1
Number Of Mono Booms 1
Number Of Dipper Options 2
Min Dipper Length 1150 mm
Max Dipper Length 1400 mm
Dipper Length 1150 mm
Operating Weight 2790 - 3090 kg
Driveline
Manufacturer Yanmar
Model 3TNV88
Aspiration Naturally Aspirated
Cooling Water
Cylinders 3
Displacement 1.642 L
Rated Speed 2400 rpm
Net Rating Standard ISO 9249
Net Output 17.9 kW
Gross Rating Standard ISO 14396
Gross Output 18.9 kW
Torque 88 Nm
Torque Rated Speed 1440 rpm
Carrier Rollers Per Side 1
Track Rollers Per Side 4
Shoe Width 250 mm
Shoe Type Rubber
Dimensions
Mono Boom 4190 mm
Without Boom 2440 - 2470 mm
Max Height 2440 - 2470 mm
Superstructure 1530 mm
Undercarriage 1550 mm
Overall Width 1550 mm
Track Length On Ground 1590 mm
Undercarriage Length 1980 mm
Tailswing Radius 775 mm
Tail Length 775 mm
Zero Tailswing No
Cab 2470 mm
Canopy 2440 mm
Counterweight Clearance 510 mm
Reference Capacity 0.07 m³
Reference Weight 58 kg
Available Standard
Type Straight
Height 295 mm
Width 1550 mm
Raised Height 440 mm
Dig Depth 315 mm
Width Over Tracks 1550 mm
Track Gauge 1300 mm
Variable Undercarriage Available No
Digging Reach 4770 mm
Ground Level Reach 4630 mm
Dig Height 4250 mm
Dump Height 2850 mm
Vertical Wall 2360 mm
Dig Depth - 2.44m (8ft) Flat Bottom 2040 mm
Dig Depth 2540 mm
Front Slew Radius 2210 mm
Front Slew Radius - Swing Boom 1930 mm
Boom Swing - Left 60 °
Boom Swing - Right 47 °
Left Digging Offset 580 mm
Right Digging Offset 645 mm
Rating Standard ISO 10567
Reach At Ground Level 3.89 m
Capacities
Fuel Tank 42 L
Engine Oil 6.7 L
Cooling System 3.8 L
Hydraulic Tank 16 L
Hydraulic System 31 L
Performance
Ground Bearing Pressure 31.3 kPa
Slew Speed 7.9 rpm
Slew Torque 4.2 kNm
Travel Speed - Low 2.6 kph
Travel Speed - High 4.4 kph
Tractive Force 27.9 kN
Boost Pressure Used For Breakout Unlisted
Dipper Tearout 14.2 kN
Bucket Breakout 20.8 kN
Gradeability 30 °
Gradeability 58 %
Internal Noise - LpA 80 dB(A)
External Noise - LwA 92 dB(A)
Lift Quoted With Bucket No
Lift Quoted With Dozer-Up/Down Up
End Lift - 2.0m 870 - 930 kg
Side Lift - 2.0m 670 - 710 kg
End Lift - 3.0m 460 - 490 kg
Side Lift - 3.0m 370 - 390 kg
End Lift - Max 320 - 340 kg
Side Lift - Max 260 - 280 kg
Main Pumps 2
Main Pump - Total 57.6 L/min
Boom 230 bar
Dipper 230 bar
Attachment 230 bar
Weights
Mono Boom 2710 - 3020 kg
